TA14-353A: Targeted Destructive Malware

Original release date: December 19, 2014 | Last revised: December 20, 2014

Systems Affected

Microsoft Windows

Overview

US-CERT was recently notified by a trusted third party of cyber threat actors using a Server Message Block (SMB) Worm Tool to conduct cyber exploitation activities recently targeting a major entertainment company. This SMB Worm Tool is equipped with a Listening Implant, Lightweight Backdoor, Proxy Tool, Destructive Hard Drive Tool, and Destructive Target Cleaning Tool.

SMB Worm Tool: This worm uses a brute force authentication attack to propagate via Windows SMB shares. It connects home every five minutes to send log data back to command and control (C2) infrastructure if it has successfully spread to other Windows hosts via SMB port 445. The tool also accepts new scan tasking when it connects to C2. There are two main threads: the first thread calls home and sends back logs (a list of successful SMB exploitations), and the second thread attempts to guess passwords for SMB connections. If the password is correctly guessed, a file share is established and file is copied and run on the newly-infected host.

Listening Implant: During installation of this tool, a portion of the binaries is decrypted using AES, with a key derived from the phrase "National Football League." Additionally, this implant listens for connections on TCP port 195 (for "sensvc.exe" and "msensvc.exe") and TCP port 444 (for "netcfg.dll"). Each message sent to and from this implant is preceded with its length, then XOR encoded with the byte 0x1F. Upon initial connection, the victim sends the string, "HTTP/1.1 GET /dns?\x00." The controller then responds with the string "200 www.yahoo.com!\x00" (for "sensvc.exe" and "msensvc.exe") or with the string "RESPONSE 200 OK!!" (for "netcfg.dll"). The controller sends the byte "!" (0x21) to end the network connection. This special message is not preceded with a length or XOR encoded.

Lightweight Backdoor: This is a backdoor listener that is designed as a service DLL. It includes functionality such as file transfer, system survey, process manipulation, file time matching and proxy capability. The listener can also perform arbitrary code execution and execute commands on the command line. This tool includes functionality to open ports in a victim host's firewall and take advantage of universal Plug and Play (UPNP) mechanisms to discover routers and gateway devices, and add port mappings, allowing inbound connections to victim hosts on Network Address Translated (NAT) private networks. There are no callback domains associated with this malware since connections are inbound only on a specified port number.

Proxy Tool: Implants in this malware family are typically loaded via a dropper installed as a service, then configured to listen on TCP port 443. The implant may have an associated configuration file which can contain a configurable port. This proxy tool has basic backdoor functionality, including the ability to fingerprint the victim machine, run remote commands, perform directory listings, perform process listings, and transfer files.

Destructive Hard Drive Tool: This tool is a tailored hard-drive wiping tool that is intended to destroy data past the point of recovery and to complicate the victim machine’s recovery. If the CNE operator has administrator-level privileges on the host, the program will over-write portions of up-to the first four physical drives attached, and over-write the master boot record (MBR) with a program designed to cause further damage if the hard drive is re-booted. This further results in the victim machine being non-operational with irrecoverable data (There is a caveat for machines installed with the windows 7 operating system: windows 7 machines will continue to operate in a degraded state with the targeted files destroyed until after reboot, in which the infected MBR then wipes the drive.) If the actor has user-level access, the result includes specific files being deleted and practically irrecoverable, but the victim machine would remain usable.

Destructive Target Cleaning Tool: This tool renders victim machines inoperable by overwriting the Master Boot Record. The tool is dropped and installed by another executable and consists of three parts: an executable and a dll which contain the destructive components, and an encoded command file that contains the actual destruction commands to be executed.

Network Propagation Wiper: The malware has the ability to propagate throughout the target network via built-in Windows shares. Based on the username/password provided in the configuration file and the hostname/IP address of target systems, the malware will access remote network shares in order to upload a copy of the wiper and begin the wiping process on these remote systems. The malware uses several methods to access shares on the remote systems to begin wiping files. Checking for existing shares via “\hostname\admin$\system32” and “\hostname\shared$\system32” or create a new share “cmd.exe /q /c net share shared$=%SystemRoot% /GRANT:everyone, FULL”. Once successful, the malware uploads a copy of the wiper file “taskhostXX.exe”, changes the file-time to match that of the built-in file “calc.exe”, and starts the remote process. The remote process is started via the command “cmd.exe /c wmic.exe /node:hostname /user:username /password:pass PROCESS CALL CREATE”. Hostname, username, and password are then obtained from the configuration file. Afterwards, the remote network share is removed via “cmd.exe /q /c net share shared$ /delete”. Once the wiper has been uploaded, the malware reports its status back to one of the four C2 IP addresses.

Technical and strategic mitigation recommendations are included in the Solution section below.

US-CERT recommends reviewing the Security Tip Handling Destructive Malware #ST13-003.

Description

Cyber threat actors are using an SMB worm to conduct cyber exploitation activities.  This tool contains five components – a listening implant, lightweight backdoor, proxy tool, destructive hard drive tool, and destructive target cleaning tool.

The SMB worm propagates throughout an infected network via brute-force authentication attacks, and connects to a C2 infrastructure.

Impact

Due to the highly destructive functionality of this malware, an organization infected could experience operational impacts including loss of intellectual property and disruption of critical systems.

Solution

Users and administrators are recommended to take the following preventive measures to protect their computer networks:

• Use and maintain anti-virus software – Anti-virus software recognizes and protects your computer against most known viruses. It is important to keep your anti-virus software up-to-date (see Understanding Anti-Virus Software for more information).
• Keep your operating system and application software up-to-date – Install software patches so that attackers can't take advantage of known problems or vulnerabilities. Many operating systems offer automatic updates. If this option is available, you should enable it (see Understanding Patches for more information).
• Review Security Tip Handling Destructive Malware #ST13-003 and evaluate their capabilities encompassing planning, preparation, detection, and response for such an event.
• Review Recommended Practices for Control Systems, and Improving Industrial Control Systems Cybersecurity with Defense-in-Depth Strategies (pdf).

The following is a list of the Indicators of Compromise (IOCs) that can be added to network security solutions to determine whether they are present on a network.

MD5s:

SMB worm tool:
